176
Parameter Description
PTZ
Activation
Select the check box and click Setting. Select the PTZ channel and PTZ
action. When an alarm occurs, NVR triggers the channel to perform the
corresponding PTZ action. For example, activate the PTZ to move to preset
point X.
Note
You shall set the corresponding PTZ actions first.
Tour
Select the check box and click Setting. Select the tour channel. When an
alarm occurs, NVR local interface displays the select channel image.
Note
You shall set tour interval and tour mode first.
Snapshot
Select the check box and click Setting. Select the snapshot channel. When an
alarm occurs, NVR triggers snapshot in the selected channel.
Note
You shall enable alarm snapshot and auto snapshot first.
Log
Select the check box. When an alarm occurs, NVR records the alarm
information in the log.
Buzzer
Select the check box. When an alarm occurs, NVR triggers the buzzer for
alarm.
Step 4 Click Apply or OK to save the configuration.
3.10.14 POS
Connect the device with the POS, the device can receive the POS information and overlay corresponding
info on the video.
Note
For the local-end, this function supports 1/4-window display and 1-window playback.
This function is for the cashier of the supermarket and etc. The device can get the information from
the POS and then overlay the txt information on the video.
Step 1 From main menu->Setting->System->POS, the interface is shown as below. See Figure 3-168.
