Dahua XVR5104HS User Manual

445
Please note the activation snapshot has the higher priority than schedule snapshot. If
you have enabled these two types at the same time, system can activate the activation
snapshot when an alarm occurs, and otherwise system just operates the schedule
snapshot.
4.9.4.1.2.4 Image FTP
In the main menu, from Setting->Storage->FTP, you can set FTP server information.
Please enable FTP function and then click save button. See Figure 4- 182.
Please boot up corresponding FTP server.
Please enable schedule snapshot (Chapter 4.9.4.1.2.1) or activation snapshot
(Chapter 4.9.4.1.2.2) first, now system can upload the image file to the FTP server.
Figure 4- 182
4.9.4.2 HDD Manager
Here is for you to view and implement hard disk management. See Figure 4- 183.
You can see current HDD type, status, capacity and etc. The operation includes format
HDD, and change HDD property (read and write/read-only/redundancy).
Please input the
corresponding information
here, if you just upload the
image FTP.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
