Dahua XVR5104HS User Manual

531
Figure 5- 58
Please refer to the following sheet for detailed information.
Parameter
Function
DDNS Type
Server name and address provided by the DDNS service
provider.

Dyndns DDNS is members.dyndns.org.

NO-IP DDNS is dynupdate.no-ip.com.

CN99 DDNS is members.3322.org.
Server IP
Domain Name
The domain name registered on the DDNS service provider
website.
User
Input the user name and password got from the DDNS service
provider. Make sure you have logged in the DDNS service
provider website to register an account (user name and
password).
Password
Update period
After DDNS boots up, it sends out refresh query regularly. The
unit is minute.
After setting, click Save button.
Input full domain name on the browser and click Enter button. The setting is right if you
can view device WEB interface. Otherwise, please check the parameters.
5.10.2.8 Sync Time Right
It is to allow the specified IP host to sync time with the device or change device time.
Background Information
If the IP host and the device are not the same, it may result in file search failure; data
backup is not the same and cannot record and operate the device. So, there is need to
specify the device and IP host time synchronization mechanism and make sure the device
and IP host time is the same.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
