Dahua XVR5104HS User Manual

532
Steps:
Step 1 From main window->Setup->Network->Sync time right.
Enter sync time interface. See Figure 5- 59.
Figure 5- 59
Step 2 Check the box to enable this function.
Step 3 Click Add button, and then set IP address in the pop-up interface click Save
button.
Refer to the following table to set parameters.
Parameter
Function
IP address
Input the device IP address you want to add.
IP segment
Input the start address and end address of the IP segment you
want to add.
IPv4
The IP address adopts IPv4 mode such as 172.16.5.10.
IPv6
The IP address adopts IPv6 mode such as
aa:aa:aa:aa:aa:aa:aa:aa.
MAC
address
Input the mac address you want to add.
Step 4 Click Save to complete setup.
Step 5 Login the device WEB on the IP host.
From Setup->System->General->Date and time, change device time or click
Sync time with PC. Device pops the corresponding dialogue box.
5.10.2.9 Email
The email interface is shown as in Figure 5-60.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
