Dahua XVR5104HS User Manual

547
Figure 5- 76
Note
Video diagnosis alarm can trigger PTZ preset, tour, and pattern.
For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed
information.
5.10.3.2 IVS (Optional)
Note
Right now, the IVS function max supports 10 rules.
Once any object violate the rule, the DVR can trigger an alarm and alert you as the
specified alarm mode.
From main menu->Setup->Event->IVS, enter IVS interface. See Figure 5-77.
Please follow the steps listed below.
Step 1 Please select a channel from the dropdown list.
Step 2 Click and then select corresponding rule.
Step 3 Set rule type and set corresponding parameters.
Step 4 Check the box to enable the rule.
Step 5 Click OK button to save current setup.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
