Dahua XVR5104HS User Manual

548
Figure 5- 77
5.10.3.2.1 Tripwire
System generates an alarm once there is any object crossing the tripwire in the specified
direction. Please use according to your actual situation.
Note
 The tripwire function is valid once your connected network camera or your DVR
supports this function.
 If you want to use the IVS function of the network camera, please make sure your
connected network camera supports this function.
Step 1 From main menu->Setup->Event->IVS->Tripwire, click to add the rule and
select the rule type as Tripwire.
Note
Double click to change a rule name.
Step 2 Check the Tripwire box to enable tripwire function. See Figure 5- 78.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
