Dahua XVR5104HS User Manual

577
Parameter
Function
Port
It is to set the time server port.
Interval
It is to set the sync periods between the device and the time server.
5.10.5.1.3 Holiday Setup
Holiday setup interface is shown as in Figure 5- 115.
Here you can click Add box to add a new holiday and then click Save button to save.
Note
Once the holiday settings is different the general date, the holiday settings has priority.
After successfully set holiday here, you can view holiday item in Schedule interface. It is
for you to set holiday schedule record/snapshot settings.
Figure 5- 115
5.10.5.2 Display
Display interface includes GUI, TV adjust, Tour and zero-channel encoding.
5.10.5.2.1 Display
Here you can set background color and transparency level. See Figure 5- 116.
Figure 5- 116

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
