Dalsa Linea Lite GigE Series User Manual

8 • Linea Lite GigE Series Overview Linea Lite GigE Series Camera
Camera Specifications Overview
Camera Controls
Synchronization Modes
Free running, External triggered, Software trigger through Ethernet or IEEE
1588 Precision Time Protocol (PTP)
Exposure Modes
Programmable increments of 1 µs
• minimum (in µs) is model specific
• maximum is 2.5 ms
Pulse controlled via Trigger pulse width
Trigger Inputs
(used as Line or Frame triggers)
RS422
Debounce range from 0 to 255 µs
Frame Trigger programmable delay up to 2,000,000 µs for 128 objects
maximum.
Strobe Outputs Aligned to the start of exposure with a programmable delay, duration and
polarity
(using “start of exposure on output line source” feature)
Features
Flat Field Correction 1 Factory FFC plus 4 User Defined FFC
Binning Digitally based: Horizontal & Vertical (2 and 4 pixel)
Digital Gain 1x to 10x (global); 1x to 8x (per channel)
Sensor Analog Gain 0.6x to 1x
Counter and Timer 1 Counter and 1 Timer
User programmable, acquisition independent with event generation
Timestamp 1 µs internal timer
Test Image Internal generator with choice of static patterns
Multicast Programming support for multicasting images (requires Multicast host support:
refer to the SDK documentation – if supported)
Action Command Programmable for up to 2 GenICam Action Commands (requires host support:
refer to the SDK documentation – if supported)
User Settings Select factory default or one of 4 user camera configurations
TurboDrive Technology Supported with 8-bit or 16-bit buffer format (see Sapera 8.60 release notes).
Linea Lite color models support TurboDrive with Bayer output (Pixel Format
BiColorRGBG8).
Onboard Memory
DDR Reserved Packet Resend Buffer 6 MB default (user defined feature)
Reserved Data Buffer 84 MB
Total Memory 128 MB
FLASH 32 MB
Back Focal Distance
M42 x 1 Mount 12 mm
M42 to Nikon F-bayonet adapter 46.5 mm
(34.5 mm for the F mount adapter plus 12 mm for the camera body)
Mechanical Interface
Camera Size 46(H) x 46(W) x 37(L) in mm
For complete dimensions Refer to Mechanical Specifications section.
Mass < 150 g (no lens)
Power Connector via HD15 GPIO connector or RJ45 in PoE mode
Ethernet Connector RJ45

Dalsa Linea Lite GigE Series Specifications

General

Brand	Dalsa
Model	Linea Lite GigE Series
Category	Digital Camera
Language	English
