10 • Linea Lite GigE Series Overview Linea Lite GigE Series Camera
Sensor Performance
The sensor description below provides a specification table and response graphics. The graph
describes the sensor response to different wavelengths of light (excluding lens and light source
characteristics). Visible light spans wavelengths between about 390 - 780 nm. Wavelengths below
390 nm are termed ultra-violet while those above 780 nm are termed infra-red.
Sensor Specifications
Item / Feature Specification
Camera Model L2-GM-02K05B-00-A L2-GM-04K02B-00-A L2-GC-02K02B-00-A L2-GC-04K01B-00-A
Sensor Used High speed CMOS line scan
Minimum Line Rate
(internal acquisition)
300 Hz (note 1)
Maximum Line Rate
(internal acquisition)
64 kHz Burst 32 kHz Burst
Sustained Line Rate
Output
(Typical, network
dependent, Turbo mode
disabled)
50 kHz (8-bit)
32 kHz (12-bit)
25 kHz (8-bit)
16 kHz (12-bit)
25 kHz (8-bit RGBG)
16 kHz (8 bit RGB)
16 kHz (12-bit packed
RGBG)
12.5 kHz (8-bit)
8 kHz (8-bit RGB)
8 kHz (12-bit packed
RGBG)
Maximum Line Rate
Output
System dependent on the GigE network
Exposure Control
5 μs to 2500 μs
Internal Trigger to Start
of Exposure
~0.24 μs minimum (programmable exposure mode)
External Trigger to Start
of Exposure
~0.30 μs minimum
(programmable and pulse width-controlled exposure modes)
Line Readout Time 15.6 μs
Pixel Size 14 µm x 14 µm 7 µm x 7 µm 14 µm x 14 µm 7 µm x 7 µm
Pixel Format User selectable 8 or 12-bit
Sensor Full Well 30 ke-
Output Dynamic Range
64 dB (nominal gain, factory calibration)
72 dB (Minimum gain, high SNR mode)
Random Noise < 2.5 DN rms (nominal gain, FFC enabled)
DC Offset 7 DN — 12-bit (FFC enabled)
PRNU (corrected) < 1.5% @ 50% Saturation
FPN (corrected) < 5 DN
SEE (@ 550nm factory
calibrated)
3.3 nJ / cm
2
20 nJ / cm
2
4 nJ / cm
2
24 nJ / cm
2
NEE (@ 550nm factory
calibrated)
2.6 pJ / cm
2
12 pJ / cm
2
3.1 pJ / cm
2
15 pJ / cm
2
Anti-blooming > 100 x Saturation
Integral non-Linearity < 2% DN
Note (1): With the external trigger, the camera will operate at slower speeds down to 0Hz. If the trigger is stopped or a timeout reached, the
camera will fill the remainder of the current frame with dark lines and wait for the next trigger. Once the triggering is restarted, the camera
will resume the operation.
Test Conditions
• Values measured using 12-bit, 1x gain
• 10 kHz line rate
• Light source: broadband, quartz halogen, 3250 K with 700 nm IR cut-off filter
• Front plate temperature: 45°C

Dalsa Linea Lite GigE Series Specifications
