Linea Lite GigE Series Camera Linea Lite GigE Camera Quick Start • 27
Camera Status LED Indicator
The camera is equipped with one multicolor LED to display the operational status of the camera.
When more than one condition is active, the LED color indicates the condition with the highest
priority (such as an acquisition in progress has more priority than a valid IP address assignment).
When the Linea Lite GigE is connected to a network, the Status LED turns a steady blue indicating
the IP address is configured by the GigE Server or application. The following table summarizes the
LED states and corresponding camera status.
LED State Definition
LED is off No power to the camera
Steady Red Initial state on power up before flashing.
Remains as steady Red only if there is a fatal error.
Camera is not initialized: Wait a few minutes for the camera to reboot.
Flashing Red Initialization sequence in progress.
Steady Red + Flashing
Blue
Fatal Error. If the camera does not reboot itself contact Technical Support.
Slow Flashing Blue Ethernet cable disconnected. The camera continuously attempts to assign
itself an IP address.
Fast Flashing Blue
File Access Feature is transferring data such as a firmware update or FCC
transfer and so forth.
Steady Blue IP address assigned but no application is connected to the camera.
Steady Green Application connected.
Flashing Green Acquisition in progress. Flashing occurs on frame acquisition but does not
exceed a rate of 100 ms for faster frame rates.
Note: If the Linea Lite GigE
has obtained an IP address, it might be on a different subnet than
the NIC it is attached to. Therefore, if the Linea Lite GigE LED is blue but an application cannot
see it, this indicates a network configuration problem; Refer to
Troubleshooting section.
LED States on Power Up
The following LED sequence occurs when the Linea Lite GigE is powered up connected to a network
with installed GigE Vision software.
Flashing Red
Initialization
Flashing Blue
Waiting for IP
Blue
IP assigned
Green
Application
connected
Red
Power connected
Figure 13: LED Power-Up Sequence
