Linea Lite GigE Series Camera Camera Performance and Features • 51
Gamma Correction Factor
The following graphic shows LUT output data as a function of the Gamma Correction factor
programmed by the user. A 12-bit LUT is shown as an example.
• As Gamma Correction is reduced in value to the minimum allowed, the nonlinear output of
acquisition data through the LUT effectively boosts low value data.
• As Gamma Correction is increased in value to the maximum allowed, the nonlinear output of
acquisition data through the LUT effectively reduces low value data.
DN = 0
DN = 4095
LUT Output
Input DN
DN = 0
DN
= 4095
Gamma Factor going to min.
Gamma Factor going to max.
Figure 40: Gamma Correction Factor (not to scale)
Related GigE Vision Features
Feature related to LUTs are part of the Advanced Processing category.
