Linea Lite GigE Series Camera Operational Reference • 113
Event Control Feature Descriptions
Display Name Feature & Values Description Standard
& View
Timestamp Latch Cmd timestampControlLatch
Latch the current timestamp internal counter value in the
Timestamp Value
feature.
Expert
DFNC
Timestamp Value timestampValue Returns the 64-bit value of the timestamp counter. (RO)
Expert
DFNC
TimeStamp Source timestampSource Specifies the source used as the incrementing signal for the
timestamp register.
Expert
DFNC
Internal Clock InternalClock The timestamp source is generated by the camera internal
clock. Refer to Timestamp Tick Frequency
feature for the
time base.
Timestamp Tick
Frequency (in Hz)
timestampTickFrequency
Indicates the number of timestamp ticks (or increments)
during 1 second (frequency in Hz). (RO)
Expert
DFNC
Timestamp Latch Source timestampLatchSource Specifies the internal event or signal that will latch the
timestamp counter into the timestamp buffer.
Expert
DFNC
Frame Start FrameStart The timestamp is latched on frame start.
Expert
DFNC
Timestamp Reset Cmd timestampControlReset Resets the timestamp counter to 0. (WO)
Expert
DFNC
Event Selector EventSelector Select the Event to enable/disable with the
EventNotification feature.
Expert
End of Frame FrameEnd Event sent on control channel on an End of Frame.
Start of Frame FrameStart
Event sent on control channel on an Active Frame. This
occurs with the start of the exposure delay of the first line
of the frame.
Valid Frame Trigger ValidFrameTrigger
Event sent on control channel when a valid frame trigger is
generated.
Rejected Frame Trigger InvalidFrameTrigger
Event sent on control channel when a frame trigger occurs
in an invalid Trigger region. The trigger is rejected and no
frame acquisition occurs.
Image Lost ImageLost
Event sent on control channel when an image is lost due to
insufficient memory.
Rejected Line Trigger InvalidLineTrigger Event sent on control channel when a line trigger occurs in
an invalid Trigger region. The trigger is rejected and no
frame acquisition occurs.
Line 1 Rising Edge Line1RisingEdge
Event sent on control channel when a rising edge is
detected on Line 1.
Line 1 Falling Edge Line1FallingEdge
Event sent on control channel when a falling edge is
detected on Line 1.
Line 2 Rising Edge Line2RisingEdge
Event sent on control channel when a rising edge is
detected on Line 2.
Line 2 Falling Edge Line2FallingEdge
Event sent on control channel when a falling edge is
detected on Line 2.
Line 3 Rising Edge Line3RisingEdge
Event sent on control channel when a rising edge is
detected on Line 3.
Line 3 Falling Edge Line3FallingEdge
Event sent on control channel when a falling edge is
detected on Line 3.
Start of Acquisition
AcquisitionStart
Event sent on control channel on acquisition start.
End of Acquisition
AcquisitionEnd
Event sent on control channel on acquisition end.
Events Overflow eventsOverflow Event sent on control channel when all previous active
events have been disabled because the camera cannot send
them fast enough, generating an internal message overflow.
All required events must be re-enabled manually.
