Linea Lite GigE Series Camera Linea Lite GigE Series Overview • 7
Part Numbers and Software Requirements
This manual covers the Linea Lite GigE models summarized below. New models are added to this
manual as they are released by Teledyne DALSA. See Camera Specifications for details of each
Linea Lite GigE model.
Camera Resolution Pixel Size Max. Line Rate
Lens Mount
(threaded)
Product Number
Linea Lite Monochrome
GigE 2k
2048 x 2 14 x 14 µm
50 kHz sustained*
64 kHz burst
M42 x 1 L2-GM-02K05B-00-A
Linea Lite Monochrome
GigE 4k
4096 x 2 7 x 7 µm
25 kHz sustained*
64 kHz burst
M42 x 1 L2-GM-04K02B-00-A
Linea Lite Color
GigE 2K
2048 x 2 14 x 14 µm
25 kHz sustained*
64 kHz burst
M42 x 1 L2-GC-02K02B-00-A
Linea Lite Color
GigE 4K
4096 x 2 7 x 7 µm
12.5 kHz sustained*
32 kHz burst
M42 x 1 L2-GC-04K01B-00-A
*Network/configuration dependent. Higher sustained line rates with Turbo mode.
Accessories Order Number
M42 x 1 to F-mount adapter for 12 mm BFD lens, heavy duty with clip AC-LA-00115-xx-R
HD15 GPIO Breakout Cable Assembly AC-CA-00002-xx-R
For a list of accessories go to http://www.teledynedalsa.com/imaging/products/cameras/accessories/
Optical filters are available from https://midopt.com/
Teledyne DALSA Software Platform
Sapera LT version 8.50 (or higher)
Sapera LT is a free image acquisition and control software development
toolkit (SDK) for Teledyne DALSA’S 2D / 3D cameras and frame grabbers.
Hardware independent in nature, Sapera LT offers a rich development
ecosystem for machine vision OEMs and system integrators.
Sapera LT includes CamExpert provides an intuitive graphical interface that
allows configuring and setup of cameras. It includes live image acquisition
with interactive parameter configuration capabilities.
Available for download:
http://www.teledynedalsa.com/imaging/support/
downloads/sdks/
GigE Vision Turbo Drive Technology Module — improved proprietary
package allows the Linea Lite GigE to sustain higher data transfers to the
host system. Contact Teledyne DALSA Sales for additional information.
Sapera Processing Imaging Development Library
(sold separately):
Contact Teledyne DALSA Sales
Third Party GigE Vision Software Platform Requirements
Support of GenICam GenApi version 2.3 General acquisition and control. File access: firmware,
FFC, configuration data, upload & download.
Support of GenICam XML schema version 1.1
Support of GigE Vision 1.2
GenICam™ support — XML camera description file Embedded within Linea Lite GigE
