Dalsa Linea Lite GigE Series User Manual

Linea Lite GigE Series Camera Operational Reference • 99
Pixel Color Filter
PixelColorFilter Indicates the type of color filter applied to the image
(RO).
Beginner
Bayer GR
BayerGR
For BayerGR, the 2x2 mosaic alignment is GR/BG.
Bayer RG
BayerRG
For BayerRG, the 2x2 mosaic alignment is RG/GB.
Bayer GB BayerGB For BayerGB, the 2x2 mosaic alignment is GB/RG.
Bayer BG BayerBG For BayerBG, the 2x2 mosaic alignment is BG/GR.
Pixel Size
PixelSize
Total size in bits of an image pixel.
Guru
8 Bpp8 8-bits per pixel.
12 Bpp12 12-bits per pixel.
24 Bpp24 24-bits per pixel.
Horizontal Offset OffsetX Horizontal offset from the sensor origin (in pixels).
Beginner
Width Width
Width of the image provided by the device (in pixels).
The minimum width is 64 pixels and can be specified in
increments of 16 pixels.
Beginner
Height Height Height of the image provided by the device (in lines).
Beginner
Multiple ROI Mode multipleROIMode
Enable the Multiple ROI (Region of Interest) per image
feature. The ROI Count is set by the Multiple ROI Count
feature.
Expert
DFNC
Off Off Single ROI per image.
Active Active The ROI per image feature is active.
ROI Count Horizontal multipleROICountHorizontal Specifies the number of ROI (Region of Interest)
available for the X axis. For the Linea Lite 2k model only
2 ROIs are available.
Expert
DFNC
ROI Count multipleROICount
Specifies the number of possible ROI (Region of Interest)
available in an acquired image. Two is minimum;
maximum is device-specific.
Expert
DFNC
ROI Selector multipleROISelector Select an ROI (Region of Interest) when Multiple ROI
Mode is enabled. Selector range is from 1 to the ROI
Count value.
Expert
DFNC
ROI (x1, y1)
roi1_1
ROI (x1, y1)
ROI (x2, y1) roi2_1 ROI (x2, y1)
ROI (x3, y1) roi3_1 ROI (x3, y1). Not available for Linea Lite 2k model.
ROI (x4, y1) roi4_1 ROI (x4, y1). Not available for Linea Lite 2k model.
ROI Offset X multipleROIOffsetX Horizontal offset (in pixels) from the origin to the
selected ROI (Region of Interest).
Expert
DFNC
ROI Width multipleROIWidth Width of the selected ROI (Region of Interest) provided
by the device (in pixels). Increment value is device
dependent.
Expert
DFNC
Binning Selector binningSelector
Select how the horizontal and vertical binning is done.
The binning function can occur in the digital domain of a
device or at the actual sensor.
Beginner
DFNC
In Digital Domain InDigitalDomain The Binning function can be done inside the device but
with a digital processing function. Binning doesn’t affect
the current data rate from the sensor or camera.
Binning Mode binningMode
Sets the mode used to combine pixels together when
Binning Horizontal and / or Binning Vertical
is greater
than 1.
Beginner
DFNC
Sum Sum
The responses from the individual pixels are added
together, resulting in increased sensitivity.
Average Average
The responses from the individual pixels are averaged,
resulting in increased signal to noise ratio.
Binning Horizontal BinningHorizontal
Number of horizontal photo-sensitive cells to combine
together. This increases the intensity of the pixels but
reduces the horizontal resolution.
Beginner
Binning Vertical BinningVertical Number of vertical photo-sensitive cells to combine
together. This increases the intensity of the pixels but
reduces the vertical resolution of the image.
Beginner
