Linea Lite GigE Series Camera Camera Performance and Features • 35
The exposure delay between rows can be reduced to 15 μs to increase the exposure overlap
between the two rows using the Row Two Exposure Delay feature.
Figure 21: Row Two Exposure Delay
2k Sensor
The Linea Lite 2k sensor has a 14 μm pixel; there is no spacing between the sensor lines, so every
time the object being imaged moves 14 μm, when using an external synchronization trigger signal
(EXSYNC), the trigger should be fired each time the object moves 14 μm.
...
0
2047
Line 1
Line 2
Cha rge
accumulation
Object
movement
(14 μm)
...
Figure 22: Object Movement & Charge Accumulation
For the 2k sensor exposure for rows one and two occur at the same time.
Figure 23: 2k Sensor Row Pulse Width Exposure
