Linea Lite GigE Series Camera Additional Reference Information • 153
Additional Reference
Information
Lens Selection Overview
This section provides a general overview to selecting a lens for the Linea Lite GigE. Mechanical
drawings and Teledyne DALSA part numbers for available lens adapters are provided.
The first two lens parameters, Lens Mount and Lens Image Circle, are based on correctly matching
the lens to the sensor. Brief information on other lens parameters to consider follows those
sections.
Lens Mount Types
Linea Lite GigE 2k / 4k cameras use a M42x1 lens screw mount and have an optional adapter for F-
mount (AC-LA-00115-xx-R) lenses, as described below.
