Dalsa Linea Lite GigE Series User Manual

92 • Operational Reference Linea Lite GigE Series Camera
LUT Value LUTValue Returns the value at specified LUT index entry of
the LUT selected by the LUT Selector feature.
Guru
Flat Field Correction
Mode
flatfieldCorrectionMode Sets the mode for the Flat Field correction.
Beginner
DFNC
Off Off Flat Field Correction is disabled.
Active
Active
Flat Field Correction is enabled.
Calibration Calibration When selected, the camera is configured for flat
field correction calibration. The device may
automatically adjust some of its features when
calibrate mode is enabled. The features that are
automatically adjusted are device specific. The
device will not restore these features when the
Flat Field Correction Mode feature is changed from
Calibrate mode to another mode.
Flat Field Correction
Current Active Set
flatfieldCorrectionCurrentActiveSet Specifies the current set of Flat Field coefficients
to use. User data is uploaded via the file access
feature.
Feature used when flatfieldCorrectionMode is
Active. In Calibration, changing this feature has
no effect unless you save the FFC, where this
feature defines where to save the values. This
feature also can be used to copy FFC sets.
Note: only 2 user sets are available for Linea Lite
GigE 2k version (L2-GM-02K05B-00-A); the Linea
Lite GigE 4k version (L2-GM-04K02B-00-A)
supports 4 user sets.
Beginner
DFNC
Factory Flatfield FactoryFlatfield Sets the factory Flat Field coefficient table as the
current Flat Field.
User Flatfield 1 UserFlatfield1 Sets User Flat Field 1 coefficient table as the
current Flat Field.
User Flatfield 2 UserFlatfield2
Sets User Flat Field 2 coefficient table as the
current Flat Field.
User Flatfield 3 UserFlatfield3
Sets User Flat Field 3 coefficient table as the
current Flat Field.
Not available for Linea Lite GigE 2k version (L2-
GM-02K05B-00-A).
User Flatfield 4 UserFlatfield4 Sets User Flat Field 4 coefficient table as the
current Flat Field.
Not available for Linea Lite GigE 2k version (L2-
GM-02K05B-00-A).
Flat Field Correction
Type
flatfieldCorrectionType Specifies the Flat Field correction type.
Guru
DFNC
Line-Based LineBase
Flat field correction is based on an individual line
(FlatLine).
Flat Field Correction
Algorithm
flatfieldCorrectionAlgorithm Specifies the Flat Field correction algorithm to
use.
Guru
DFNC
Method 1 Method1 The following formula is used to calculate the flat
field corrected pixel: newPixelValue[x] =
(sensorPixelValue[x] - FFCOffset[x]) *
FFCGain[x])
Calibration
Algorithm
flatfieldCorrectionCalibrationAlgorithm Specifies the flatfield calibration algorithm to use.
Guru
DFNC
Peak Peak Each pixel is gained up to the brightest.
Set Target SetTarget Each pixel is gained up to the value specified in
the flatfieldCalibrationTarget feature.
Flat Field Calibration
Target (in DN)
flatfieldCalibrationTarget
Sets the target pixel value for the gain (PRNU)
calibration.
Expert
DFNC
Flat Field Calibration
Sample Size
flatfieldCalibrationSampleSize
Set flat field calibration sample size (number of
lines to sum).
Guru
DFNC
2048
Lines_2048
2048
4096 Lines_4096 4096
