150 • Technical Specifications Linea Lite GigE Series Camera
Output Signals Electrical Specifications
External Outputs Block Diagrams
Balanced RS422 Drive
Output Signal
OUTPUT (+)
PIN 5
Signal Ground
External Output
Signal
Single-Ended Logic Drive
3.3 V TTL
OUTPUT (-)
not connected
OUTPUT (-)
Output Enable
Output Signal
OUTPUT (+)
PIN 5
Signal Ground
Output Enable
External Output
Signal
Single-Ended Open Collector Mode
5 V, 12 V, 24 V
OUTPUT (-)
not connected
Output Signal
OUTPUT (+)
PIN 5
Signal Ground
Output Enable
External Output
Signal
Figure 105: External Outputs Block Diagram
