Linea Lite GigE Series Camera Linea Lite GigE Series Overview • 9
Optical Interface
Sensor Alignment (Relative to sides of camera)
Flatness 50 µm
Θ y 100 µm (Parallelism vs. front plate)
x ± 300 µm (Cross-Scan Direction)
y ± 300 µm (In-Scan Direction)
z ± 300 µm (Along optical axis)
Θ z ± 0.4° (Rotation around optical axis)
Electrical Interface
Input Voltage +12 to +24 Volts DC (+20% / -10%)
Supports Power Over Ethernet standard (PoE Class 2 as per IEEE 802.3af)
Power Dissipation < 5 W
Operating Temperature 0 to 60°C at front plate
Relative Humidity 5% to 90% non-condensing (operating)
Output Data Configuration Gigabit Ethernet with PAUSE Frame support (as per IEEE 802.3x)
Data and Control GigE Vision compliant
Environmental Specifications
Environmental Specifications Performance
Storage temperature range -20°C to +80°C
Humidity (storage and operation) 15% to 85% relative, non-condensing
MTBF (mean time between failures) > 100,000 hours, typical field operation
