Linea Lite GigE Series Camera Operational Reference • 97
5. On the red channel of the dark-subtracted red image, average all odd-numbered pixels and
save as R (refer to Figure 79).
6. Calculate the blue crosstalk correction value with the average of the Gr and the average of
the Gb pixels in the dark-subtracted blue image:
Blue Crosstalk correction value =
()
× 100
7. Calculate the red crosstalk correction value with the average of the Gr and the average of
the Gb pixels in the dark-subtracted red image:
Red Crosstalk correction value =
()
× 100
These values should be entered for features crosstalkCorrectionBlue and crosstalkCorrectionRed,
and the corrections re-enabled.
