Terminal Locations - D3h/D4h
Take the following position of the terminals into consideration when designing the cable access.
1
130BC523.10
Figure 7.6 Position of Ground Terminals IP20 (Chassis), D3h/D4h
1
Ground Terminals
Table 7.4 Legend to Figure 7.5 and Figure 7.6
Electrical Installation
Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 183
