FC 302 P450 P500 P560 P630 P710 P800
High/Normal load* HO NO HO NO HO NO HO NO HO NO HO NO
Typical shaft output at 400 V [kW] 450 500 500 560 560 630 630 710 710 800 800 1000
Typical shaft output at 460 V [HP] 600 650 650 750 750 900 900 1000 1000 1200 1200 1350
Typical shaft output at 500 V [kW] 530 560 560 630 630 710 710 800 800 1000 1000 1100
Enclosure IP21, IP54 without/with
options cabinet
F1/ F3 F1/ F3 F1/ F3 F1/ F3 F2/ F4 F2/ F4
Output current
Continuous (at 400 V) [A] 800 880 880 990 990 1120 1120 1260 1260 1460 1460 1720
Intermittent (60 s overload)
(at 400 V) [A]
1200 968 1320 1089 1485 1232 1680 1386 1890 1606 2190 1892
Continuous (at 460/500 V) [A] 730 780 780 890 890 1050 1050 1160 1160 1380 1380 1530
Intermittent (60 s overload)
(at 460/500 V) [A]
1095 858 1170 979 1335 1155 1575 1276 1740 1518 2070 1683
Continuous kVA (at 400 V) [kVA] 554 610 610 686 686 776 776 873 873 1012 1012 1192
Continuous kVA (at 460 V) [kVA] 582 621 621 709 709 837 837 924 924 1100 1100 1219
Continuous kVA
(at 500 V) [kVA]
632 675 675 771 771 909 909 1005 1005 1195 1195 1325
Maximum input current
Continuous (at 400 V) [A] 779 857 857 964 964 1090 1090 1227 1227 1422 1422 1675
Continuous (at 460/500 V) [A] 711 759 759 867 867 1022 1022 1129 1129 1344 1344 1490
Max. cable size, motor [mm
2
(AWG)
1)
]
8x150 (8x300 mcm) 12x150 (12x300 mcm)
Max. cable size, line power F1/F2
[mm
2
(AWG)
1)
]
8x240 (8x500 mcm)
Max. cable size, line power F3/F4
[mm
2
(AWG)
1)
]
8x456 (8x900 mcm)
Max. cable size, load sharing [mm
2
(AWG)
1)
]
4x120 (4x250 mcm)
Max. cable size, brake
[mm
2
(AWG)
1)
4x185 (4x350 mcm) 6x185 (6x350 mcm)
Max. external electrical fuses [A]
2)
1600 2000 2500
Estimated power loss
at 400 V [W]
3) 4)
9031 10162 10146 11822 10649 12512 12490 14674 14244 17293 15466 19278
Estimated power loss
at 460 V [W]
3)
4)
8212 8876 8860 10424 9414 11595 11581 13213 13005 16229 14556 16624
F3/F4 max. added losses A1 RFI, CB
or Disconnect, & contactor F3/F4
893 963 951 1054 978 1093 1092 1230 2067 2280 2236 2541
Max. panel options losses 400
Weight, enclosure IP21, IP54 [kg] 1017/1318 1260/1561
Weight, rectifier module [kg] 102 102 102 102 136 136
Weight, inverter module [kg] 102 102 102 136 102 102
Efficiency
4)
0.98
Output frequency 0–590 Hz
Heatsink overtemp. trip 230 °F [110 °C]
Control card ambient trip 185 °F [85 °C]
* High overload=160% torque during 60 s, Normal overload=110% torque during 60 s.
Table 4.3 Technical Specifications, F-frames, 380–500 V Line Power Supply 3x380–500 V AC
1) American Wire Gauge.
2) For fuse ratings, see chapter 7.2.1 Fuses.
3) Typical power loss is at normal conditions and expected to be within
±
15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the adjustable frequency drive.
