Danfoss VLT AutomationDrive FC 300 Design Guide

If the switching frequency is raised from nominal, the power losses rise significantly. LCP and typical control card power consumptions are
included. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B
each add only 4 W.
4) Measured using 16.5 ft. [5 m] shielded motor cables at rated load and rated frequency.
FC 302 P250 P315 P355 P400
High/Normal load* HO NO HO NO HO NO HO NO
Typical shaft output at 400 V [kW] 250 315 315 355 355 400 400 450
Typical shaft output at 460 V [HP] 350 450 450 500 500 600 550 600
Typical shaft output at 500 V [kW] 315 355 355 400 400 500 500 530
Enclosure IP21 F8/F9 F8/F9 F8/F9 F8/F9
Enclosure IP54 F8/F9 F8/F9 F8/F9 F8/F9
Output current
Continuous (at 400 V) [A] 480 600 600 658 658 745 695 800
Intermittent (60 s overload)
(at 400 V) [A]
720 660 900 724 987 820 1043 880
Continuous (at 460/500 V) [A] 443 540 540 590 590 678 678 730
Intermittent (60 s overload)
(at 460/500 V) [A]
665 594 810 649 885 746 1017 803
Continuous KVA (at 400 V) [KVA] 333 416 416 456 456 516 482 554
Continuous KVA (at 460 V) [KVA] 353 430 430 470 470 540 540 582
Continuous KVA (at 500 V) [KVA] 384 468 468 511 511 587 587 632
Maximum input current
Continuous (at 400 V) [A] 472 590 590 647 647 733 684 787
Continuous (at 460/500 V) [A] 436 531 531 580 580 667 667 718
Max. cable size, line power
[mm
2
(AWG)
1)
]
4x90 (3/0) 4x90 (3/0) 4x240 (500 mcm) 4x240 (500 mcm)
Max. cable size, motor [mm
2
(AWG)
1)
]
4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm)
Max. cable size, brake [mm
2
(AWG)
1)
]
2x185 (2x350 mcm) 2x185 (2x350 mcm) 2x185 (2x350 mcm) 2x185 (2x350 mcm)
Max. external electrical fuses [A]
2)
700
Estimated power loss
at 400 V [W]
3) 4)
5164 6790 6960 7701 7691 8879 8178 9670
Estimated power loss
at 460 V [W]
3) 4)
4822 6082 6345 6953 6944 8089 8085 8803
Weight, enclosure IP21, IP54 [kg] 447/669
Efficiency
4)
0.98
Output frequency 0–590 Hz
Heatsink overtemp. trip 230 °F [110 °C]
Control card ambient trip 185 °F [85 °C]
* High overload=160% torque during 60 s, Normal overload=110% torque during 60 s.
Table 4.4 Technical Specifications F8/F9 Frames, 380–500 Line Power Supply 6x380–500 V AC, 12-Pulse
1) American Wire Gauge.
2) For fuse ratings, see chapter 7.2.1 Fuses.
3) Typical power loss is at normal conditions and expected to be within ± 15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the adjustable frequency drive.
If the switching frequency is raised from nominal, the power losses rise significantly. LCP and typical control card power consumptions are
included. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B
each add only 4 W.
4) Measured using 16.5 ft. [5 m] shielded motor cables at rated load and rated frequency.
Selection
Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 67
4 4
