Design Guide | VLT® AutomationDrive FC 360
Table 52: Query
Field name Example (hex)
Follower address 01 (drive address)
Function 05 (write single coil)
Coil address HI 00
Coil address LO 40 (64 decimal) Coil 65
Force data HI FF
Force data LO 00 (FF 00 = ON)
Error check (CRC) –
Response
The normal response is an echo of the query, returned after the coil state has been forced.
Table 53: Response
Field name Example (hex)
Follower address 01
Function 05
Force data HI FF
Force data LO 00
Quantity of coils HI 00
Quantity of coils LO 01
Error check (CRC) –
9.10.4 Force/Write Multiple Coils (0F hex)
Description
This function forces each coil in a sequence of coils to either on or off. When broadcasting, the function forces the same coil references in
all attached followers.
Query
The query telegram specifies the coils 17–32 (speed setpoint) to be forced.
 NOTICE
Coil addresses start at 0, that is, coil 17 is addressed as 16.
Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295 | 109
