Design Guide | VLT® AutomationDrive FC 360
Table 10: J8–J9 Power/Semiconductor Fuse Sizes (continued)
Model 380–480 V
H200/Q250 ar-630
H250/Q315 ar-800
Table 11: J8–J9 Power/Semiconductor Fuse Options, 380–480 V
Fuse optionsModel
Bussman Littelfuse Littelfuse Bussman Siba Ferraz-
Shawmut
Ferraz-
Shawmut
(Europe)
H90K/Q110 170M2619 LA50QS300-4 L50S-300 FWH-300A 20 189 20.315 A50QS300-4 6,9URD31D08
A0315
H110/Q132 170M2620 LA50QS350-4 L50S-350 FWH-350A 20 189 20.350 A50QS350-4 6,9URD31D08
A0350
H132/Q160 170M2621 LA50QS400-4 L50S-400 FWH-400A 20 189 20.400 A50QS400-4 6,9URD31D08
A0400
H160/Q200 170M4015 LA50QS500-4 L50S-500 FWH-500A 20 189 20.550 A50QS500-4 6,9URD31D08
A0550
H200/Q250 170M4016 LA50QS600-4 L50S-600 FWH-600A 20 189 20.630 A50QS600-4 6,9URD31D08
A0630
H250/Q315 170M4017 LA50QS800-4 L50S-800 FWH-800A 20 189 20.800 A50QS800-4 6,9URD31D08
A0800
Table 12: J8–J9 Space Heater Fuse Recommendation
Bussmann Rating
LPJ-21/2SP 2.5 A, 600 V
NOTICE
DISCONNECT SWITCH
All units ordered and supplied with a factory-installed disconnect switch require Class L branch circuit fusing to meet the 100 kA
SCCR for the drive. If a circuit breaker is used, the SCCR rating is 42 kA. The input voltage and power rating of the drive determine
the specific Class L fuse. The input voltage and power rating are found on the product nameplate.
7.6 Motor
7.6.1 Motor Rotation
Any 3-phase asynchronous standard motor can be used with a drive.
Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295 | 57
