Minimum cross-section to relay terminals 0.2 mm
2
(30 AWG)
Length of stripped wire 8 mm (0.3 in)
Relay 01 terminal number 1–3 (break), 1–2 (make)
Maximum terminal load (AC-1)
1)(1)
on 1–2 (NO) (Resistive load)
2)(2)
400 V AC, 2 A
Maximum terminal load (AC-15)
(1)
on 1–2 (NO) (Inductive load @
cosφ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
(1)
on 1–2 (NO) (Resistive load) 80 V DC, 2 A
Maximum terminal load (DC-13)
(1)
on 1–2 (NO) (Inductive load) 24 V DC, 0.1 A
Maximum terminal load (AC-1)
(1)
on 1–3 (NC) (Resistive load) 240 V AC, 2 A
Maximum terminal load (AC-15)
(1)
on 1–3 (NC) (Inductive load @
cosφ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
(1)
on 1–3 (NC) (Resistive load) 50 V DC, 2 A
Maximum terminal load (DC-13)
(1)
on 1–3 (NC) (Inductive load) 24 V DC, 0.1 A
Minimum terminal load on 1–3 (NC), 1–2 (NO) 24 V DC 10 mA, 24 V AC 2 mA
Environment according to EN 60664-1 Overvoltage category III/pollution degree 2
Relay 02 terminal number 4–6 (break), 4–5 (make)
Maximum terminal load (AC-1)
(1)
on 4–5 (NO) (Resistive load)
(2)
400 V AC, 2 A
Maximum terminal load (AC-15)
(1)
on 4–5 (NO) (Inductive load @
cosφ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
(1)
on 4–5 (NO) (Resistive load) 80 V DC, 2 A
Maximum terminal load (DC-13)
(1)
on 4–5 (NO) (Inductive load) 24 V DC, 0.1 A
Maximum terminal load (AC-1)
(1)
on 4–6 (NC) (Resistive load) 240 V AC, 2 A
Maximum terminal load (AC-15)
(1)
on 4–6 (NC) (Inductive load @
cosφ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
(1)
on 4–6 (NC) (Resistive load) 50 V DC, 2 A
Maximum terminal load (DC-13)
(1)
on 4–6 (NC) (Inductive load) 24 V DC, 0.1 A
Minimum terminal load on 4–6 (NC), 4–5 (NO) 24 V DC 10 mA, 24 V AC 2 mA
Environment according to EN 60664-1 Overvoltage category III/pollution degree 2
1) IEC 60947 part 4 and 5.
2) Overvoltage Category II.
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
5.13 Control Card, RS485 Serial Communication
Terminal number 68 (P, TX+, RX+), 69 (N, TX-, RX-)
Terminal number 61 Common for terminals 68 and 69
32 | Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295
Design Guide | VLAutomationDrive FC 360
