Danfoss VLT AutomationDrive FC 360 Design Guide

11 How to Order a Drive
11.1 Drive Configurator
Configure the correct drive for the proper application by using the internet-based Drive Configurator. The Drive Configurator is found
on the global internet site: Low Voltage Drives | Danfoss Global Product Store. The configurator creates a type code string and an 8-digit
sales number, which can be delivered to the local sales office. It is also possible to build a project list with several products and send it to
a Danfoss sales representative.
F
C
-
T
e30bv168.10
X
S
A BX X X X
1
2
3
4
5
6
7
8 9
10 11 12
13
14 15 16 17 18 19 20 302221 23 272524 26 28 29 31 32
X
3
6
0
4
E
2
0 H 2
X X
C
X
X
Figure 69: Type Code String
An example of a type code string is:
FC-360Q110T4E20H2XXCXXXSXXXXA0BX
The meaning of the characters in the string is defined in this chapter. In the example above, a drive is configured with the following
options:
l RFI filter, Class A2.
l 3C3.
l PROFIBUS DP-V1.
Drives are delivered automatically with English, Chinese, and Portuguese.
11.2 Ordering VLT® AutomationDrive FC 360 Enclosure Size J8–J9
Table 75: Ordering Type Code for Enclosures J8–J9
Description Pos Possible choice
Product group 1–6 FC-360
Model 7–10 • Q110: 110 kW (150 hp)
• Q132: 132 kW (200 hp)
• Q160: 160 kW (250 hp)
• Q200: 200 kW (300 hp)
• Q250: 250 kW (350 hp)
• Q315: 315 kW (450 hp)
• H90K: 90 kW (125 hp)
• H110: 110 kW (150 hp)
• H132: 132 kW (200 hp)
• H160: 160 kW (250 hp)
• H200: 200 kW (300 hp)
• H250: 250 kW (350 hp)
Mains voltage 11–12 T4: 380–480 V AC
Enclosure 13–15 E20: IP20
RFI filter 16–17 H2: RFI filter, class A2
Brake 18 X: No brake IGBT
130 | Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295
Design Guide | VLT® AutomationDrive FC 360
