Page #35 background imageLoading...
Page #35 background image
Design Guide | VLAutomationDrive FC 360
The RS485 serial communication circuit is galvanically isolated from the supply voltage (PELV).
5.14 Control Card, 24 V DC Output
Terminal number 12
Maximum load 100 mA
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital inputs
and outputs.
5.15 Control Card, +10 V DC Output
Terminal number 50
Output voltage 10.5 V ±0.5 V
Maximum load 15 mA
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high voltage terminals.
5.16 Control Characteristics
Resolution of output frequency at 0–500 Hz ±0.003 Hz
System response time (terminals 18, 19, 27, 29, 32, and 33) ≤2 ms
Speed control range (open loop) 1:100 of synchronous speed
Speed accuracy (open loop) ±0.5% of nominal speed
Speed accuracy (close loop) ±0.1% of nominal speed
All control characteristics are based on a 4-pole asynchronous motor.
5.17 Control Card Performance
Scan interval 1 ms
Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295 | 33
