Bit 11 = 1: Relay 01 activated if [36] Control word bit 11 is selected in parameter 5-40 Function Relay.
Bit 12, Relay 02
Bit 12 = 0: Relay 02 is not activated.
Bit 12 = 1: Relay 02 is activated if [37] Control word bit 12 is selected in parameter 5-40 Function Relay.
Bit 13, Set-up selection
Use bit 13 to select from the 2 menu setups according to the following table.
Table 64: Menu Setups
Setup Bit 13
1 0
2 1
The function is only possible when [9] Multi set-ups is selected in parameter 0-10 Active Set-up.
To define how bit 13 gates with the corresponding function on the digital inputs, use parameter 8-55 Set-up Select.
Bit 15 Reverse
Bit 15 = 0: No reversing.
Bit 15 = 1: Reversing. In the default setting, reversing is set to digital in parameter 8-54 Reversing Select. Bit 15 causes reversing only
when serial communication [2] Logic OR or [3] Logic AND is selected.
9.11.2 Status Word According to FC Profile (STW)
Set parameter 8-30 Protocol to [0] FC.
Follower-master
e30ba273.11
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Figure 62: Status Word
Table 65: Status Word According to FC Profile
Bit Bit value=0 Bit value=1
00 Control not ready Control ready
01 Drive not ready Drive ready
02 Coasting Enable
03 No error Trip
04 No error Error (no trip)
05 Reserved –
06 No error Trip lock
116 | Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295
