Danfoss VLT AutomationDrive FC 360 Design Guide

Table 9: Terminal Descriptions (continued)
Terminal Parameter Default setting Description
20 – – Common for digital inputs and 0 V
potential for 24 V supply.
Analog inputs/outputs
50 – +10 V DC 10 V DC analog supply voltage. 15
mA maximum commonly used for
potentiometer or thermistor.
53 Parameter group 6-1* Analog Input 1 Reference
54 Parameter group 6-2* Analog Input 2 Feedback
Analog input. Selectable for voltage
or current.
42 Parameter 6-91 Terminal 42 Analog
Output
[0] No operation
45 Parameter 6-71 Terminal 45 Analog
Output
[0] No operation
Programmable analog output. The
analog signal is 0–20 mA or 4–20 mA
at a maximum of 500 Ω. Can also be
configured as digital outputs.
55 – – Common for analog input.
Serial communication
61 – – Integrated RC-filter to connect cable
shield if there are EMC problems.
68(+) Parameter group 8-3* FC Port
Settings
–
69(-) Parameter group 8-3* FC Port
Settings
–
RS485 interface. A switch is provided
on the control card for bus termina-
tion resistance.
Relays
01, 02, 03 Parameter 5-40 Function Relay [0] [0] No operation
04, 05, 06 Parameter 5-40 Function Relay [1] [0] No operation
Form C relay output. For AC or DC
voltage and resistive or inductive
loads.
7.5 Fuses and Circuit Breakers
Fuses ensure that possible damage to the drive is limited to damages inside the unit. To ensure compliance with EN 50178, use the
recommended fuses as replacements. Use of fuses on the supply side is mandatory for IEC 60364 (CE) compliant installations.
Type aR fuses are recommended for enclosures J8–J9.
Table 10: J8–J9 Power/Semiconductor Fuse Sizes
Model 380–480 V
H90K/Q110 ar-315
H110/Q132 ar-350
H132/Q160 ar-400
H160/Q200 ar-500
56 | Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295
