5.18.4 J9 Terminal Dimensions
33 (1.3) 91 (3.6)
149 (5.8)
211 (8.3)
265 (10.4)
319 (12.6)
200 (7.9)
319 (12.6)
e30bg616.10
0.0
o.o
1
2
3
Figure 16: J9 Terminal Dimensions (Front View)
1 Mains terminals 2 Motor terminals
3 Ground terminals
