Design Guide | VLT® AutomationDrive FC 360
B
e30bf804.10
B
857 (33.7)
A
A
320 (12.6)
280 (11.0)
350 (13.8)
107
(4.2)
213 (8.4)
1122 (44.2)
1096 (43.1)
1051 (41.4)
271 (10.7)
130 (5.1)
25 (1.0)
33 (1.3)
11 (0.4)
40
(1.6)
11 (0.4)
9 (0.3)
20 (0.8)
24 (0.9)
Figure 15: Back View of J9
