5 Specifications
5.1 Electrical Data
Table 3: Electrical Data for Normal Overload, Mains Supply 3x380–480 V AC
Drive Q110 Q132 Q160 Q200 Q250 Q315
Enclosure size J8 J8 J8 J9 J9 J9
Normal overload=110% current during 60 s
Typical shaft output at 400 V [kW] 110 132 160 200 250 315
Typical shaft output at 460 V [hp] 150 200 250 300 350 450
Output current (3-phase)
Continuous (at 400 V) [A] 212 260 315 395 480 588
Intermittent (60 s overload) (at 400 V) [A] 233 286 347 435 528 647
Continuous (at 460 V) [A] 190 240 302 361 443 535
Intermittent (60 s overload) (at 460 V) [A] 209 264 332 397 487 589
Continuous kVA (at 400 V) [kVA] 147 180 218 274 333 407
Continuous kVA (at 460 V) [kVA] 151 191 241 288 353 426
Maximum input current
Continuous (at 400 V) [A] 204 251 304 381 463 567
Continuous (at 460 V) [A] 183 231 291 348 427 516
Maximum number and size of cables per phase
Mains and motor [mm
2
(AWG)] 2x95 (2x3/0) 2x185 (2x350 mcm)
Maximum external mains fuses [A] 315 350 400 550 630 800
Estimated power loss at 400 V [W] 2559 2954 3770 4116 5137 6674
Estimated power loss at 460 V [W] 2261 2724 3628 3569 4566 5714
Efficiency [%] 98
Output frequency [Hz] 0–590
Heat sink overtemperature trip [°C (°F)] 110 (230)
Control card overtemperature trip [°C (°F)] 75 (167) 80 (176)
Table 4: Electrical Data for High Overload, Mains Supply 3x380–480 V AC
Drive H90K H110 H132 H160 H200 H250
Enclosure size J8 J8 J8 J9 J9 J9
High overload=150% current during 60 s
Typical shaft output at 400 V [kW] 90 110 132 160 200 250
Typical shaft output at 460 V [hp] 125 150 200 250 300 350
26 | Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295
Design Guide | VLT® AutomationDrive FC 360
