Danfoss VLT AutomationDrive FC 360 - Page 40

M10
13 (0.5)
32 (1.3)
59 (2.3)
10 (0.4)
244 (9.6)
272 (10.7)
0.0
0.0
1
2
4
3
5
M10
13 (0.5)
32 (1.3)
145 (5.7)
182 (7.2)
3X M8x18
0
0
e30bg573.10
Figure 12: J8 Terminal Dimensions (Side Views)
1 Mains terminals 2 Motor terminals
3 Ground terminals 4 Mains terminals
5 Motor terminals
