Datalogic DS2400N User Manual

INTRODUCTION
2
2.4 MODEL DESCRIPTION
The DS2400N scanner is available in versions that differ in regard to the following
parameters:
• Reading range
• Linear or raster reading
DS2400N - X X X 0
Reading Range
0 = Short
1 = Medium
2 = Long
Communication Interface
2= RS232/RS485main + RS232 aux
+ RS485 ID-NET™
Optic Version
0 = Linear
1 = Raster
The following tables display each version’s reading performance.
Version Max Code Resolution Speed
mm (mils) scans/s
02X0 0.20 (8) 600 to 1000
12X0 0.25 (10) 600 to 1000
22X0 0.35 (14) 600 to 1000
Version Reading Distance
02X0 75 mm (3 in) - 340 mm (13.4 in) on 0.35 mm (14 mils) codes
12X0 100 mm (3.9 in) - 440 mm (17.3 in) on 0.50 mm (20 mils) codes
22X0 190 mm (7.5 in) - 600 mm (23.6 in) on 0.50 mm (20 mils) codes
See reading diagrams in par. 4.4 for further details.
23

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
