4.3 PERFORMANCE
The DS2400N scanner is available in different versions according to the reading
performance.
Version Max Code Resolution Speed
mm (mils) scans/s
02X0 0.20 (8) 600 to 1000
12X0 0.25 (10) 600 to 1000
22X0 0.35 (14) 600 to 1000
Version Reading Distance
02X0 75 mm (3 in) - 340 mm (13.4 in) on 0.35 mm (14 mils) codes
12X0 100 mm (3.9 in) - 440 mm (17.3 in) on 0.50 mm (20 mils) codes
22X0 190 mm (7.5 in) - 600 mm (23.6 in) on 0.50 mm (20 mils) codes
Refer to the diagrams given in par. 4.4 for further details on the reading features.
They are taken on various resolution sample codes at a 25
°C ambient temperature,
depending on the conditions in the notes under the diagrams.
4.3.1 Raster
Raster versions are available. If standard devices do not satisfy specific
requirements, contact your nearest Datalogic distributor, supplying code samples, to
obtain complete information on the reading possibilities.
The reading characteristics for the raster version is given in the table below. The
distance between the top and bottom scan lines is given at different reading
distances measured from the laser beam output window.
Reading Distance
300 mm
(11.8 in)
600 mm
(23.6 in)
Raster Capture
18 mm
(0.7 in)
35 mm
(1.4 in)
60

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
