Datalogic DS2400N User Manual

DS2400N
2
2.5 ACCESSORIES
The following accessories are available on request for the DS2400N:
Name Description Part Number
GFC-200 Contact Reading Mirror 93A201106
GFC-2000 105° Reading Mirror 93A201080
GFC-2100 90° Reading Mirror 93A201000
OM2000 Oscillating Mirror 93A251031
INT-30 (for C-Box 100) 20 mA Current Loop Interface Board 93A151022
C-BOX 100 Passive Connection Box 93ACC1510
C-BOX 150 Parameters Storage Connection Box 93A301066
C-BOX 200 (*) Active Connection Box 93ACC1520
C-BOX 300/310 (*) Profibus Connection Box 93A301000,
93A301030
C-BOX 400/410 (*) DeviceNet Connection Box 93A301010,
93A301040
MEP-542/543 Photocell Kit PNP/NPN 93ACC1727,
93ACC1728
PG-6000/6001/6002 24 V Power Supply Unit EU/UK/US 93ACC1720,
93ACC1719,
93ACC1718
(*) = partially compatible; refer to your local technical support office for details.
24

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
