Datalogic DS2400N User Manual

TROUBLESHOOTING
6
6 TROUBLESHOOTING
6.1 GENERAL GUIDELINES
When wiring the device, pay careful attention to the pin number of the signals and
whether you are referring to the scanner connector or to the C-BOX 100
/150 spring
clamp connectors.
If you need information about a certain reader parameter you can refer to the
Genius™program help files.
Either connect the device and select the parameter you’re interested in by pressing
the F1 key, or select Help/Parameters Help/2000 Software Configuration
Parameters Guide from the command menu.
If you’re unable to fix the problem and you’re going to contact your local Datalogic
office or Datalogic Partner or ARC, we suggest providing (if possible) the Device
Configuration files (*.
ddc). Connect through Genius™and click the Save icon from
the
toolbar. Also note the exact Model, Serial Number and Order Number of the
device.
65

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
