Datalogic DS2400N User Manual

DS2400N
3
3.3.3 ID-NET™
C-BOX 100/150 Pin Name Function
38 ID-NET+ High speed internal network+
36 ID-NET- High speed internal network-
39 GND ground
The following instructions are referred to Figure 23, Figure 24 and Figure 25:
• Use DeviceNet cables (drop type 2 x AWG 24 + 2 x AWG 22).
• Cable Shield connected only to Master earth.
• Max 1000 meter ID-NETcable length.
• Connect only 36, 38 and not 39 (use only 2 wires).
• DC Voltage Power cable (VS – GND) should be handled as a signal cable (i.e.
do not put it together with AC cable):
- Wire dimensioning must be checked in order to avoid voltage drop greater
than 0.8 Volt.
- Cable should lie down as near as possible to the ID-NET cable (avoiding
wide loop between them).
• Scanner's chassis may be connected to earth.
• Network inside the same building.
38

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
