DS2400N
1
ADVANCED SCANNER CONFIGURATION
For further details on advanced product configuration, refer to the complete
Reference Manual on the installation CD-ROM or downloadable from the web site
through this link: www.datalogic.com/DS2400N.
The following are alternative or advanced scanner configuration methods:
Host Mode Programming
The scanner can also be configured from a host computer using the Host Mode
programming procedure, by commands via the serial interface. See the Host Mode
Programming file on the CD-ROM.
Advanced Genius™ Configuration
The ADVANCED selection available when starting the Genius™ program is
addressed to expert users being able to complete a detailed scanner configuration.
By choosing this option it is possible either to start a new scanner configuration or to
open and modify an old one. The desired parameters can be defined in the following
window, similar to the MS Explorer:
Figure 9 - Genius™ Parameter Explorer Window
14

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
