DS2400N
7
7 TECHNICAL FEATURES
DS2400N-0XX0 DS2400N-1XX0 DS2400N-2XX0
ELECTRICAL FEATURES
Input Power
Supply voltage 10 to 30 Vdc
Power consumption max. 5 W
Serial Interfaces
Main RS232; RS485 Full-duplex / Half-duplex;
(20 mA C.L. only with C-Box 100 and INT-30 accessory)
Auxiliary RS232
Baudrate 1200 to 115200
ID-NET™ Interface
RS485 Half Duplex
Baudrate up to 500000
Inputs
External Trigger Optocoupled, polarity insensitive
IN2
not-optocoupled NPN only
Voltage
Ext. Trig.: 5 to 30 Vdc
IN2: (VS –5) to 0 Vdc
Current Consumption 12 mA max.
Outputs
OUT1, OUT2 Optocoupled
V
CE
30 Vdc max.
Collector current 40 mA continuous max.; 130 mA pulsed
V
CE
saturation 1V at 10 mA max.
Power dissipation max.
80 mW at 45
°C (ambient temperature)
OPTICAL FEATURES
Light source Semiconductor laser diode
Wave length (Note 1) 630 to 680 nm
Safety class Class 2 - EN 60825-1; Class II - CDRH
READING FEATURES (Note 2)
Scan rate software programmable (600 to 1000 scans/sec)
Aperture angle 50°
Maximum Reading distance 340 mm (13.4 in) 440 mm (17.3 in) 600 mm (23.6 in)
Maximum resolution 0.20 mm (8 mils) 0.25 mm (10 mils) 0.35 mm (14 mils)
USER INTERFACE
LED indicators
READY, GOOD, TRIGGER, COM, STATUS, POWER ON
X-PRESS™ button
68

Table of Contents

Other manuals for Datalogic DS2400N

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic DS2400N and is the answer not in the manual?

Datalogic DS2400N Specifications

General IconGeneral
Type-
Sensor typeLaser
Read rate (max)1000 reads/s
Linear (1D) barcodes supportedCodabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supportedNot supported
Standard interfacesRS-232, RS-485
Connectivity technologyWired
Input voltage10 - 30 V
Power source typeDC
Power consumption (typical)5 W
CertificationIEC
Product colorBlue, Yellow
Housing materialAluminum
International Protection (IP) codeIP65
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)0 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth34 mm
Width84 mm
Height68 mm
Weight330 g
