TECHNICAL FEATURES
7
SOFTWARE FEATURES
READABLE CODE SYMBOLOGIES
* EAN/UPC (including Add-on 2 and Add-on 5 * Codabar
2/5 Interleaved * Code 93
* Code 39 (Standard and Full ASCII) * ABC Codabar
* Code 128 ISBT 128
* EAN 128 Pharmacode
* = ACB Readable. Other symbologies available on request.
Code Selection up to ten different codes during one reading phase
Decoding Safety can enable multiple good reads of same code
Headers and Terminators
Up to 128-byte header string
Up to 128-byte terminator string
Operating Modes
On-Line, Serial On-Line, Verifier,
Automatic, Continuous, Test
Configuration Modes
•
Genius™ utility program
• Genius™ based Host Mode Programming
• X-PRESS™ Functions
Special Functions
ACB (Advanced Code Builder)
Motor Off
Parameter Storage Non-volatile internal Flash
ENVIRONMENTAL FEATURES
Operating temperature (Note 3)
0 to +45
°C (+32 to +113 °F)
Storage temperature
-20 to +70
°C (-4 to +158 °F)
Humidity max. 90% non condensing
Vibration resistance IEC 68-2-6 test FC
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70 to 200 Hz; 2 hours on each axis
Shock resistance IEC 68-2-27 test EA
30g; 11 ms; 3 shocks on each axis
Protection class IP65
PHYSICAL FEATURES
Mechanical dimensions 68 x 84 x 34 mm (2.68 x 3.31 x 1.34 in)
Weight 330 g (11.6 oz)
Note 1: The features given are typical at a 25 °C ambient temperature (if not otherwise
indicated).
Note 2: Further details given in par. 4.3.
Note 3: If the reader is used in high temperature environments (over 35 °C), use of the
Beam-shutter is advised (see the Genius™ configuration program).
69
