Datalogic DS2400N User Manual

INSTALLATION
3
The table below gives the pinout of the C-BOX 100 terminal block connectors. Use
this pinout when the DS2400N reader is connected in a network by means of the C-
BOX 100:
C-BOX 100 Terminal Block Connectors
Power
1, 3, 5 VS
2, 4, 6 GND
7, 8 EARTH GROUND
20, 40 Reserved
Inputs
27 EXT TRIG A (polarity insensitive)
28 EXT TRIG B (polarity insensitive)
29 NC
30 IN2-
31, 33 NC
32, 34 NC
39 GND
Outputs
21 OUT 1+
22 OUT 1-
23 OUT 2+
24 OUT 2-
25 NC
26 NC
Auxiliary Interface
35 TX AUX
37 RX AUX
ID-NET™
36 ID-NET-
38 ID-NET+
Main Interface
RS232
RS485
Full-Duplex
RS485
Half-Duplex
20 mA C.L.
(with INT-30 only)
11, 15 TX 232 TX 485+ RTX 485+
12, 16 RTS 232 TX 485- RTX 485-
17 RX 232 RX 485+
18 CTS 232 RX 485-
10, 14, 19 SGND SGND SGND
9, 13
RS485
Cable Shield
RS485
Cable Shield
see INT-30 instructions
31

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
