Calibrating the Scale (Pounds & Kilograms)
Product Reference Guide 5-5
Figure 5-1. Calibration Switch Access
4. Press and release the Calibration Switch to place the scanner/scale in
Calibration Mode. The scanner/scale will sound a tone indicating it
is in Calibration Mode. If the motor was spinning when you initi-
ated Calibration Mode, the motor will stop and the Yellow LED will
begin flashing indicating the scale is in Calibration Mode. The dis-
play will show the message “ESCL” (empty scale).
5. Reinstall the weigh platter.
6. Press the Zero Push Button. The Yellow LED will go out for
approximately 10 seconds (or less) and the Remote Display will
alternately display and until the scale is
ready to proceed.
7. When the scale is ready, the Yellow LED will begin blinking again
and the display will show the message “Ad20 (add twenty pounds)”
or “Ad10 (add ten kilograms).” The scanner/scale will also sound
one tone if the scale is weighing in kilograms or two tones for
pounds. Place the correct weight (twenty pounds for calibration in
pounds, or ten kilograms for metric calibration) from the Field
Standard Weight set on the center of the weighing area and press the
Zero Push Button again.
Spider
Calibration
Switch
