B-8 Magellan
®
8300/8400
Remote Display
Connector Hardware
4 pin SDL
Cable Pinout
Table B-7Remote Display Cable Pinouts
PIN # FUNCTION DESCRIPTION
1 +12V OUT +12V out
2 LINE_A_DSPLY LINE A Display
3 LINE_B_DSPLY LINE B Display
4 GND Ground
