Datalogic Magellan 83 Product Reference Guide

Scanner and Scanner/Scale Nomenclature
Product Reference Guide 1-5
Scanner and Scanner/Scale Nomenclature
Controls, indicators and other nomenclature are shown in Figure 1-1.
Figure 1-1. Scanner/Scale Nomenclature
Produce Bar
in raised position
All Weighs™ Platter
Scanner LED
Weighing Surface — Lean
Oversize Produce Here
Vertical Window
Horizontal
Window
Scale Zero
Push Button
Speaker (Beeper) Port
Volume/Tone
Push Button
Bonnet

Datalogic Magellan 83 Specifications

General

Brand	Datalogic
Model	Magellan 83
Category	Barcode Reader
Language	English
