Interleaved 2 of 5 (I 2 of 5) Enable
Product Reference Guide 6-311
I 2 of 5 Length 1
Length 1 is the minimum label length if in variable length mode, or the
first fixed length if in fixed length mode (see
I 2 of 5 Length Control).
Length includes the barcode’s check and data characters.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET I 2 of 5 LENGTH 1 below. You’ll need to
cover any unused bar codes on this and the facing page to ensure
that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired label length. The selectable range for this option is
002 to 050, even numbers only. Pad all single and double digit
numbers with leading zeroes to yield a three-digit entry (002-050).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET I 2 of 5 LENGTH 1
To Next Page
