Datalogic Magellan 83 Product Reference Guide

EAS Comm Port (Sensormatic
®
systems
Product Reference Guide B-9
EAS Comm Port (Sensormatic
®
systems ONLY)
EAS Deactivator Control Box Connection
Connector Hardware
RJ4
Cable Pinout
Table B-8. EAS Port Cable Pinouts
PIN # FUNCTION DESCRIPTION
1GNDGND
2 +5V Out +5V Out
3 External Read Indicator When configured, signifies good read
4 Audio Out
Intended to drive an external amplifier that
drives and external speaker.
