6-26 Magellan
®
8300/8400
Auxiliary Port Baud Rate
Specifies the baud rate of the auxillary port when operating in PIR/CT
mode.
To specify the Auxiliary Port Baud Rate:
1. Scan the SWITCH bar code.
2. Scan the desired baud rate from the bar codes below and on the
immediately following pages. You’ll need to cover any unused bar
codes on this and the facing page to ensure that the scanner reads
only the bar code you intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
AUXILIARY PORT BAUD RATE = 1200
AUXILIARY PORT BAUD RATE = 2400
NOTE
PIR/CT is a value-added feature which may not have been activated on your
model.
