G-6 Magellan
®
8300/8400
EAN-13
• Check digit must be included in label data and is assumed to be cor-
rect
• Prefix must be an ASCII character 'F'- total length including prefix
must be 14
• Example: 'F1101234567891'
EAN-13 with 2-Digit Supplemental
• Check digit must be included in label data and is assumed to be cor-
rect
• Supplemental data is appended to base label
• Prefix must be an ASCII character 'F'- total length including prefix
must be 16
• Example: 'F110123456789112'
EAN-13 with 5-Digit Supplemental
• Check digit must be included in label data and is assumed to be cor-
rect.
• Prefix must be an ASCII character 'F'- total length including prefix
must be 19.
• Example: 'F110123456789112345'.
EAN-13 with Code 128 Supplemental
• Check digit must be included in label data and is assumed to be cor-
rect
• Supplemental data is appended to base label
• Prefix must be an ASCII character 'F'- total length including prefix
must be greater or equal to 20 (code 128 Supplemental codes are
variable length having a minimum of 2 data characters)
• Characters immediately following base label must be of the form
'8100', '8101' or '8102'
• Example: 'F11012345678918100000951'
